New
0 km
Location:
Kingston
Engine: 271cc, liquid-cooled, 4-stroke, SOHC 2-valve-per-cylinder single
Bore x Stroke: 72.7 x 65.2 mm
Compression Ratio: 11.0:1
Fuel System: Carburettor: CVK32
Ignition: Full transistor digital ignition
Starting: Electric with recoil backup
Lubrication: Forced lubrication, wet sump
Transmission: CTV with centrifugal clutch, 2-speed automatic with reverse
Final drive: 2WD, shaft
Frame: Double cradle, tubular steel
Front Suspension / Wheel Travel: Double wishbone with adjustable preload / 131 mm (5.2 in)
Rear Suspension / Wheel Travel: Swingarm with adjustable preload / 141 mm (5.6 in)
Rake / Trail: 3.5° / 16 mm
Steering Angle (L/R): 39° / 39°
Front Tires: MAXXIS AT 22 x 7-10
Rear Tires: MAXXIS AT 22 x 10-10
Front Brakes: Dual ø180 mm discs with single-piston calipers
Rear Brake: ø180 mm disc with single-piston caliper
Parking Brake: Mechanical (engages rear brake)
Dimensions (LxWxH): 1,915 x 1,080 x 1,170 mm (75.4 x 42.5 x 46.1 in)
Wheelbase: 1,165 mm (45.9 in)
Road Clearance: 155 mm (6.1 in)
Seat Height: 845 mm (33.3 in)
Curb Mass**: 243 kg (536 lb)
Fuel Capacity: 12 litres
Tread (L/R): 850 mm (33.5 in) / 830 mm (32.7 in)
Turning Radius: 2.8 m (9.2 ft)
Towing Capacity: 227 kg (500 lb)
Instrumentation: Speedometer, trip meter, fuel and temperature gauges, clock, and neutral, reverse and high-beam indicators
Warranty: 12 months
Kawasaki Protection Plus: 12 / 24 / 36 / 48 months
Front Suspension: Double arm independent suspension, hydraulic shock absorber, five adjustments spring preloads
Front Travel: 160 mm (6.7 in.)
Front Tires: AT 25 X 8-12
Rear Travel: 210 mm (8.6 in.)
Front Suspension:
Cornwall
Rear Suspension: Double arm independant suspension, hydraulic shock absorber, five adjustments spring preloads
Rear Brake Type: Front and rear brake disk system
Rear Tires: AT 25 X 10-12
Passengers:
Odometer:
Brand:
Model:
Body Style:
Dry Weight: 395 kg (870 lb.)
Rear Rack Capacity: 20 kg (44 lb.) / 40 kg (88 lb.)
Towing Capacity: 396 kg (873 lb.)
Fuel Capacity : 18 L (4.76 gal.)
Ground Clearance: 270 mm (10.6 in.)
Machine Dimensions (LxWxH): 2 035 x 1 180 x 1 220 mm (80.1 x 46.4 x 48 in.)
Wheelbase: 1280 (50.3 in.)
