New
0 km
Location:
Kingston
Engine: 90cc, air-cooled, 4-stroke, SOHC 2-valve-per-cylinder single
Bore x Stroke: 47.0 x 51.8 mm
Compression Ratio: 10.0:1
Fuel System: Carburettor: Keihin PTE16
Ignition: CDI
Starting: Electric with kick backup
Lubrication: Forced lubrication, wet sump
Transmission: Automatic, CVT with centrifugal clutch
Final drive: Chain
Frame: Double cradle, steel
Front Suspension / Wheel Travel: Single A-arm with twin shocks / 71 mm (2.8 in)
Rear Suspension / Wheel Travel: Swingarm with single shock / 74 mm (2.9 in)
Rake / Trail: 3.8° / 15 mm
Steering Angle (L/R): 30° / 30°
Front Tires: AT 18 x 7-8
Rear Tires: AT 18 x 9-8
Front Brakes: Dual mechanical drums
Rear Brake: Hydraulic disc
Parking Brake: Mechanical (drum)
Dimensions (LxWxH): 1,425 x 900 x 925 mm (56.1 x 35.4 x 36.4 in)
Wheelbase: 965 mm (38.0 in)
Road Clearance: 100 mm (3.9 in)
Seat Height: 650 mm (25.6 in)
Curb Mass**: 122 kg (269 lb)
Fuel Capacity: 5.3 litres
Tread (L/R): 675 mm (26.6 in) / 665 mm (26.2 in)
Turning Radius: 2.7 m (8.9 ft)
Warranty: 12 months
Kawasaki Protection Plus: 12 / 24 / 36 / 48 months
Front Suspension: Double arm independent suspension, hydraulic shock absorber, five adjustments spring preloads
Front Travel: 160 mm (6.7 in.)
Front Tires: AT 25 X 8-12
Rear Travel: 210 mm (8.6 in.)
Front Suspension:
Cornwall
Rear Suspension: Double arm independant suspension, hydraulic shock absorber, five adjustments spring preloads
Rear Brake Type: Front and rear brake disk system
Rear Tires: AT 25 X 10-12
Passengers:
Odometer:
Brand:
Model:
Body Style:
Dry Weight: 395 kg (870 lb.)
Rear Rack Capacity: 20 kg (44 lb.) / 40 kg (88 lb.)
Towing Capacity: 396 kg (873 lb.)
Fuel Capacity : 18 L (4.76 gal.)
Ground Clearance: 270 mm (10.6 in.)
Machine Dimensions (LxWxH): 2 035 x 1 180 x 1 220 mm (80.1 x 46.4 x 48 in.)
Wheelbase: 1280 (50.3 in.)
