New
0 km
Location:
Kingston
Engine: 233cc, air-cooled, 4-stroke, SOHC 2-valve single
Bore x Stroke: 67.0 x 66.0 mm
Compression Ratio: 9.4:1
Fuel System: Fuel injection: Ìü32 mm x 1
Ignition: Digital
Starting: Electric
Lubrication: Forced lubrication, wet sump
Transmission: 6-speed, return
Clutch: Wet multi-disc, manual
Final Drive: Chain
Frame: Perimeter, high-tensile steel
Front Suspension / Wheel Travel: Ìü37 mm telescopic fork / 250 mm (9.8 in)
Rear Suspension / Wheel Travel: New Uni Trak with adjustable spring preload / 251 mm (9.9 in)
Rake / Trail: 26.5å¡ / 113 mm
Steering Angle (L/R): 45å¡ / 45å¡
Front Tire: 80/100-21 51M
Rear Tire: 100/100-18 59M
Front Brake: Ìü240 mm petal disc with dual-piston caliper
Rear Brake: Ìü220 mm petal disc with single-piston caliper
Dimensions (L x W x H): 2,045 x 840 x 1,200 mm (80.5 x 33.1 x 47.2 in)
Wheelbase: 1,360 mm (53.5 in)
Road Clearance: 300 mm (11.8 in)
Seat Height: 925 mm (36.4 in)
Curb Mass**: 115 kg (254 lb)
Fuel Capacity: 6.6 litres
Warranty: 6 months
Kawasaki Protection Plus: 12 / 24 / 36 / 48 months
Front Suspension: Double arm independent suspension, hydraulic shock absorber, five adjustments spring preloads
Front Travel: 160 mm (6.7 in.)
Front Tires: AT 25 X 8-12
Rear Travel: 210 mm (8.6 in.)
Front Suspension:
Cornwall
Rear Suspension: Double arm independant suspension, hydraulic shock absorber, five adjustments spring preloads
Rear Brake Type: Front and rear brake disk system
Rear Tires: AT 25 X 10-12
Odometer:
Brand:
Model:
Body Style:
Dry Weight: 395 kg (870 lb.)
Rear Rack Capacity: 20 kg (44 lb.) / 40 kg (88 lb.)
Towing Capacity: 396 kg (873 lb.)
Fuel Capacity : 18 L (4.76 gal.)
Ground Clearance: 270 mm (10.6 in.)
Machine Dimensions (LxWxH): 2 035 x 1 180 x 1 220 mm (80.1 x 46.4 x 48 in.)
Wheelbase: 1280 (50.3 in.)
