New
0 km
Location:
Kingston
Engine: 999cc, liquid-cooled, 4-stroke, DOHC 4-valve-per-cylinder parallel twin
Bore x Stroke: 92.0 x 75.1 mm
Compression Ratio: 11.5:1
Fuel System: Fuel injection: ø50 mm x 2
Ignition: Digital
Starting: Electric
Lubrication: Forced lubrication, wet sump
Transmission: Dual-range (high/low) CVT with centrifugal clutch and reverse
Final Drive: 2WD/4WD, shaft
Frame: Ladder type, tubular steel
Front Suspension / Wheel Travel: Double wishbone, FOX 2.5 LSC Piggyback Shocks, fully adjustable preload, and 24-position adjustable compression damping / 472 mm (18.6 in)
Rear Suspension / Wheel Travel: 4-link trailing arm rear suspension, FOX 2.5 LSC Piggyback Shocks, fully adjustable preload, and 24-position adjustable compression damping / 536 mm (21.1 in)
Steering: Rack and pinion with Electric Power Steering
Rake / Trail: 10.0° / 65 mm
Steering Angle (L/R): 34° (IN) / 29° (OUT), 34° (IN) / 29° (OUT)
Front Tires: MAXXIS Carnivore 31 x 10.00R15 8PR, with bead-lock wheels
Rear Tires: MAXXIS Carnivore 31 x 10.00R15 8PR, with bead-lock wheels
Front Brakes: Dual ø258 mm discs with twin-piston (ø32 mm x2) calipers
Rear Brakes: Dual ø258 mm discs with single-piston (ø38 mm x1) calipers
Parking Brake: Auto-adjust mechanical disc
Dimensions (LxWxH): 3,305 x 1,730 x 1,895 mm (130.1 x 68.1 x 74.6 in)
Wheelbase: 2,510 mm (98.8 in)
Road Clearance: 350/365 mm (standard/max preload) (13.8/14.4 in (standard/max preload))
Seat Height: 795 mm (31.3 in)
Curb Mass**: 893 kg (1,969 lb)
Fuel Capacity: 40 litres
Tread (F/R): 1,505 mm (59.3 in) / 1,510 mm (59.4 in)
Turning Radius: 6.2 m (20.3 ft)
Cargo Bed Dimensions (LxWxH): 370 x 840 x 230 mm (14.6 x 33.1 x 9.1 in)
Cargo Bed Capacity: 159 kg (351 lb)
Seating Capacity: 2
Vehicle Load Capacity: 354 kg (780 lb)
Lighting: 2x LED headlights
Instrumentation: Multi-function digital meter with bar-style tachometer (2 display options), digital speedometer, bar-style fuel gauge, gear indicator (L, H, N, R), Power Mode, driving mode (2WD/4WD/4WD+Diff Lock) indicator, Economical Riding Indicator, clock, odometer, dual trip meters, hour meter, water temperature, digital battery gauge, bar-style CVT temperature gauge, seatbelt warning lamp, oil warning lamp, engine check lamp, water temperature warning lamp, neutral indicator lamp, reverse indicator lamp, parking indicator lamp, EPS warning lamp, CVT belt warning lamp, low-battery warning lamp
Warranty: 6 months
Kawasaki Protection Plus: 12 / 24 / 36 / 48 months
Front Suspension: Double arm independent suspension, hydraulic shock absorber, five adjustments spring preloads
Front Travel: 160 mm (6.7 in.)
Front Tires: AT 25 X 8-12
Rear Travel: 210 mm (8.6 in.)
Front Suspension:
Cornwall
Rear Suspension: Double arm independant suspension, hydraulic shock absorber, five adjustments spring preloads
Rear Brake Type: Front and rear brake disk system
Rear Tires: AT 25 X 10-12
Odometer:
Brand:
Model:
Body Style:
Dry Weight: 395 kg (870 lb.)
Rear Rack Capacity: 20 kg (44 lb.) / 40 kg (88 lb.)
Towing Capacity: 396 kg (873 lb.)
Fuel Capacity : 18 L (4.76 gal.)
Ground Clearance: 270 mm (10.6 in.)
Machine Dimensions (LxWxH): 2 035 x 1 180 x 1 220 mm (80.1 x 46.4 x 48 in.)
Wheelbase: 1280 (50.3 in.)
