New
0 km
Location:
Kingston
Rated Output: 5.0 kW {6.8 PS} / 2,800 rpm
Max Output: 9.0 kW {12 PS} / 2,600 – 4,000 rpm
Max Torque: 40 Nm {4.1 kg®Õm} / 0 – 1,600 rpm
Motor: Air-cooled, interior permanent magnet synchronous motor
Riding Modes: ROAD / ECO
Max Speed by Mode: 85 km/h / 62 km/h
Max Speed by Mode (with e-boost): 101 km/h / 72 km/h
Electric Consumption: 43 Wh/km [LA-4, including charger energy use]
Range: 67 km [LA-4]
Battery: Lithium-ion battery pack x2
Battery Voltage/Capacity: 50.4 V / 30 Ah x2
Battery Weight: 11.5 kg x2
Battery Charging Time: 3.7 h x2
Final Drive: Chain
Frame: Trellis, high-tensile steel
Front Suspension / Wheel Travel: Ìü41 mm telescopic fork / 120 mm (4.7 in)
Rear Suspension / Wheel Travel: Bottom-link Uni Trak, gas-charged shock with adjustable spring preload / 133 mm (5.2 in
Rake / Trail: 24.4å¡ / 93 mm
Steering Angle (L/R): 35å¡ / 35å¡
Front Tire: 100/80-17M/C 52S
Rear Tire: 130/70-17M/C 62S
Front Brake: Ìü290 mm disc with dual-piston caliper
Rear Brake: Ìü220 mm disc with dual-piston caliper
Dimensions (L x W x H): 1,980 x 730 x 1,035 mm (78.0 x 28.7 x 40.7 in)
Wheelbase: 1,370 mm (53.9 in)
Road Clearance: 170 mm (6.7 in)
Seat Height: 785 mm (30.9 in)
Curb Mass**: 135 kg (298 lb) with batteries
Instrumentation: Full-colour TFT screen with riding mode indicator, e-boost gauge, battery pack temperature gauge, battery pack charge level gauges, clock, connected device notifications (Bluetooth, mail, telephone), shift position indicator (N, D, F, R), speedometer, odometer, dual trip meters, current electric consumption, average electric consumption, cruising range, and a host of indicators
Warranty: 24 months
Front Suspension: Double arm independent suspension, hydraulic shock absorber, five adjustments spring preloads
Front Travel: 160 mm (6.7 in.)
Front Tires: AT 25 X 8-12
Rear Travel: 210 mm (8.6 in.)
Front Suspension:
Cornwall
Rear Suspension: Double arm independant suspension, hydraulic shock absorber, five adjustments spring preloads
Rear Brake Type: Front and rear brake disk system
Rear Tires: AT 25 X 10-12
Odometer:
Brand:
Model:
Body Style:
Dry Weight: 395 kg (870 lb.)
Rear Rack Capacity: 20 kg (44 lb.) / 40 kg (88 lb.)
Towing Capacity: 396 kg (873 lb.)
Fuel Capacity : 18 L (4.76 gal.)
Ground Clearance: 270 mm (10.6 in.)
Machine Dimensions (LxWxH): 2 035 x 1 180 x 1 220 mm (80.1 x 46.4 x 48 in.)
Wheelbase: 1280 (50.3 in.)
